Product Features:

• High Durability: Resistant to physical damage, chemical exposure, and UV degradation, ensuring long-term performance.
• Waterproof & Impermeable: Effectively prevents water or waste from leaking into the surrounding soil or groundwater, maintaining hygiene and environmental integrity.
• UV Stabilized: Designed to withstand prolonged exposure to sunlight without degrading, making it ideal for outdoor use.
• Chemical Resistance: Highly resistant to agricultural chemicals, fertilizers, and organic waste, ensuring it remains functional even in challenging environments.
• Cost-Effective: Reduces maintenance costs and prevents potential damage to the environment, making it a cost-efficient solution for livestock farms.
• Eco-Friendly: Prevents soil and water contamination, promoting sustainable farming practices and meeting environmental protection standards.
• Easy Installation: Lightweight, flexible, and easy to install, reducing labor costs and installation time.

Product Specifications:

• Material: HDPE (High-Density Polyethylene) or LLDPE (Linear Low-Density Polyethylene)
• Thickness: Typically 0.5mm to 2.0mm (customizable as per requirements)
• Width: 4m, 6m, 8m (custom widths available)
• Length: Customizable per project requirements
• Color: Black (standard) or other colors available on request
• Tensile Strength: ≥ 25 MPa
• Elongation at Break: ≥ 300%
• Puncture Resistance: ≥ 800N
• UV Resistance: ≥ 80% retention after 1000 hours of exposure to UV light
• Temperature Resistance: Effective in temperatures ranging from -40°C to +60°C

Applications:

• Manure Storage Pits & Lagoons: Used to line manure storage facilities to prevent leachate leakage and protect the surrounding environment.
• Livestock Waste Management: Effective for lining waste disposal areas, ensuring containment and preventing water contamination.
• Agricultural Waste Treatment Systems: Used to line biogas digesters, composting systems, and other organic waste treatment systems.
• Livestock Housing Areas: Provides impermeable surfaces for feeding and bedding areas to prevent waste seepage into the ground.
• Water & Soil Protection: Installed in areas prone to waste runoff or contamination, protecting the local water table and soil quality.
• Environmental Protection: Used in sensitive ecological areas to prevent waste from spreading and damaging ecosystems, promoting sustainable farming.

Construction & Installation Recommendations:

1. Site Preparation: Ensure that the installation site is clean, smooth, and free from sharp objects that could puncture the membrane. The surface should be compacted and level to ensure optimal performance.
2. Membrane Placement: Unroll the membrane carefully, ensuring it is free of wrinkles and folds. Overlap edges (typically 100mm to 200mm) to prevent any gaps.
3. Seaming & Welding: Use hot-wedge welding or extrusion welding techniques to join the seams of the membrane. All seams should be tested for strength and integrity before proceeding.
4. Edge Protection: Consider placing protective layers of soil or sand over the edges of the membrane to prevent damage from external forces or during subsequent activities.
5. Quality Control: Regularly check for any defects or punctures during installation. Perform hydrostatic or vacuum testing to confirm the integrity of seams and membrane.
6. Weather Considerations: Install the membrane during dry, calm weather to prevent exposure to excessive moisture, which may interfere with proper bonding and welding.
